    MPO To MPO Fiber Optic Patch Cord 12F LSZH OM3 1260 - 1650nm Wavelength

    MPO To MPO 12f LSZH OM3 Fiber Optic Patch Cord Mpo Trunk Cable


    OM3 Fiber Optic Patch Cord Mpo Trunk Cable


    Specially designed for fast Ethernet, Fiber Channel,perfect for the demands of Fiber Professionals.
    High quality material: The fiber optic jumper jacket is made of friendly PVC or LSZH material, soft body but wearable.Ceramic connectors ensure low loss, and high reliability.
    Widely used: Strong compatibility, compatible with all standard fibre optic equipments and connectors, can be used for
    various types of optical fiber LAN, optical fiber communication system, instruments,CATV,CCTV and so on.


    Product Features:

    High Performance in IL & RL

    4,8,12 and 24 fiber connector terminations and assemblies

    Designed for low loss and standard loss SM and MM applications

    Economical solution for mass-termination of fiber

    Suitable for MPO/MTP application

    Ruggedized round cable, oval cable and bare ribbon options available

    Color coded housings available to differentiate fiber type, polish type and/or connector grade

    Compliant to directive 200/95/EC(RoHS)

    MPO connector complies with IEC-61754-7

    MTP/MPO Specifications:


    TypeSingle ModeSingle ModeMulti Mode
    (APC Polish)(UPC Polish)(PC Polish)
    Fiber Count8,12,24 etc.8,12,24 etc.8,12,24 etc.
    Fiber TypeG652D,G657A1 etc.G652D,G657A1 etc.OM1,OM2,OM3 etc.
    Maximum Insertion LossEliteStandardEliteStandardEliteStandard
    Low LossLow LossLow Loss
    ≤0.35 dB≤0.75dB≤0.35 dB≤0.75dB≤0.35 dB≤0.60dB
    Return Loss≥60 dB≥60 dBNA
    Durability≥500 times≥500 times≥500 times
    Operating Temperature-40℃ ~ +80℃-40℃ ~ +80℃-40℃ ~ +80℃
    Test Wavelength1310nm1310nm1310nm
    Application:

    Data communication network

    Optical System Access network

    Storage area networking fiber channel

    High density architectures


    Note: Maximum Bandwidths of Different Multimode Fibers
    OM1 – 62.5/125um – 10GBit up to 33 meters (108 feet)
    OM2 – 50/125um – 10GBit up to 82 meters (270 feet)
    OM3 – 50/125um, Laser Optimized – 10GBit up to 300 meters (984 feet)
    OM4 – 50/125um, Laser Optimized – 10GBit up to 550 meters (1805 feet)
