    1X16 ABS Box PLC Splitter , SC UPC FTTB FTTH Fiber Optic Cable Splitter

    Ask Lasest Price
    Brand Name : Hochiry
    Model Number : ABS 1X16-PLC
    Certification : CE ROHS FCC
    Price : 6.0USD/PCS
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 50000 Pieces per Week
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    1X16 ABS Box PLC Splitter , SC UPC FTTB FTTH Fiber Optic Cable Splitter

    ABS 1X16 PLC SC UPC FTTB FTTH Optic Fiber Plc Splitter ABS Box Type PLC Fiber Optic Splitter
    The fiber optic splitter is one of the most important passive devices in the optical fiber link. Waveguides are fabricated using lithography onto a silica glass substrate, which allows for routing specific percentages of light. As a result, PLC splitters offer accurate and even splits with minimal loss in an efficient package.
    It is an optical fiber tandem device with many input and output terminals, especially applicable to a passive optical network (EPON, GPON, BPON, FTTX, FTTH etc.) to connect the MDF and the terminal equipment and to branch the optical signal.
    Main characteristics:
    • Main passive PON component
    • Wave range 1260nm-1650nm
    • Best attenuation rates
    • Low insertion loss
    • Large directivity
    • Low PDL level

    Specification


    900um steel tube fiber optic splitter technical specifications
    Model nameABS 1X16-PLC
    Wavelength(nm)1260-1650
    Free SampleYES
    MaterialPVC;ABS
    DesignOEM & ODM
    ConnectorsFC, SC, ST , LC, LC/APC, SC/APC, MU and FC/APC
    fiber optic connectors are available
    Parameters1x21x41x81x161x321x641x128
    Insertion Loss (dB)≤4.2≤7.4≤10.7≤13.9≤17.2≤21.5≤24
    PDL (dB)≤0.2≤0.2≤0.3≤0.3≤0.3≤0.4≤0.5
    Uniformity (dB)≤0.6≤0.8≤0.8≤1.0≤1.5≤2.0≤2.0
    Return Loss (dB)≥50
    Directivity (dB)≥55
    Temperature Range (°C)-40~+75
    Storage Temperature (°C)-40~+85
    NOTE: The above parameter is for splitter with connector, if w/o connector, insertion loss will reduce by 0.2dB.

    Application

    1)Optical Signal Distribution
    2)Data Communications
    3)Lan and CATV System
    4)FTTX Deployment
    5)FTTH Network
    6)Passive Optical Networks (PON)
    7)Measuring System and Laser System
    8)DWDM and CWDM Systems


    1X16 ABS Box PLC Splitter , SC UPC FTTB FTTH Fiber Optic Cable Splitter1X16 ABS Box PLC Splitter , SC UPC FTTB FTTH Fiber Optic Cable Splitter
