    Light Weight Lifepo4 Lithium Battery Cabinet Storage With Wheel 48V 400Ah 20KWH

    Ask Lasest Price
    Brand Name : Hochiry
    Certification : TUV
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 10000 Piece per week
    Delivery Time : 10-15 work days
    • Product Details
    • Company Profile

    Light Weight Lifepo4 Lithium Battery Cabinet Storage With Wheel 48V 400Ah 20KWH

    Long Life Cycle LiFePO4 Batteries 5U 48V 200Ah Lithium Battery Pack Module


    Specification
    No.ItemGeneral ParameterRemark
    1Combination method16S8P
    2Rated Capacity400AhStandard discharge after Standard charge(package)
    3Factory Voltage51.2VMean Operation Voltage
    4Voltage at end of Discharge46VMean Operation Voltage
    5Charging Voltage58.4V
    6Internal Impedance≤40mΩ

    Internal resistance measured at AC 1KH Z after 50% charge The measure must uses the

    new batteries that within one week after shipment and cycles less than 5 times

    7Standard chargeConstant Current 100ACharge time : Approx 4.5h
    Maximum Charge250A
    8Standard dischargeConstant current:100A
    9Maximum Continuous
    Discharge Current
    250A
    10Maximum Discharge
    Current
    40A
    11Operation Temperature
    Range
    Charge: 0~45℃60±25%R.H.Bare Cell
    Discharge: -20~55℃
    12Storage Temperature
    Range
    Less than 12 months : -10~35℃60±25%R.H.at the shipment state
    Less than 3 months: -10~45℃
    Less than 7 day : -20~65℃
    13Dimensions(L*W*H) 820*460*700mmInclude case
    14Weight250kgInclude case

    RDUCS DISPLAY



    PRODUCT ADVANTAGE


    product-GSL ENERGY-img


    APPLICATION


    Energy Storage

    --Solar-Wind Power System / City Grid (On/Off) / Community and Family
    Back-up System and UPS
    --Telcom Base / CATV system / Computer Server Center / Medical Instrumnt / Military Equipment
    Other Applications
    --Security and Electronics / Mobile POS, Mining Lihgt / Torch / LED Light / Emergency Light
    --RV Motorhome /Golf Carts Battery / Boat Marine Yachts / Electric Skateboard
    --LED Backup / Engine Starting Battery,etc.


    PACKING

    product-GSL ENERGY-img

    Good Quality Packs
    product-GSL ENERGY-img-1

    Low Quality Packs

    SUPER SAFETY TEST


    product-GSL ENERGY-img-1

    Passed the below abuse and safety test-short-circuit, dropping, nail penetration, impact, crush, thermal shock, over-charge,over-discharge: no fire, no explosion with stable chemical structure.


    WHY CHOOSE US


    Experience--More than 12 years Specialized in lithium battery, Leaders of Lithium Lifepo4 Battery.
    Certification--CE,UL,MSDS,Test Report from National Center For Quality Supervision and Inspection of Battery Products approved.
    Quality Control-- 37 production process,7 steps quality check to promise stable quality and high reliability for you.
    Best Material-- Insist on choosing top quality cell, material and accessories,lithium battery last longer time.
    Fresh battery-- All battery is fresh Production.


    product-GSL ENERGY-GSL ENERGY Light Weight 48V 400Ah 20KWH Wheel Design Lifepo4 Battery System Stora-1
